Special lead-acid battery for coal mine
keyword：
Positive electrode plate
Category：
Specification of conventional Yuguang battery
|
Battery model |
5h rated capacity（Ah） |
Rated voltage（V） |
Reference appearance size（mm） |
||
|
L |
W |
H |
|||
|
D330KT |
330 |
2 |
136 |
179 |
460 |
|
D385KT |
385 |
2 |
136 |
179 |
460 |
|
D440KT |
440 |
2 |
173 |
179 |
460 |
|
D440KT(B) |
440 |
2 |
125 |
158 |
515 |
|
D560KT |
560 |
2 |
145 |
160 |
580 |
|
D560KT(A) |
560 |
2 |
125 |
158 |
611 |
|
D450KT |
450 |
2 |
93 |
158 |
625 |
|
DM330KT |
330 |
2 |
182 |
140 |
390 |
|
DM385KT |
385 |
2 |
182 |
140 |
390 |
|
DM440KT |
440 |
2 |
180 |
166 |
390 |
- Descriptioin
- Product Features
- Application field
-
- Commodity name: Special lead-acid battery for coal mine
- Commodity ID: 1113487139866824704
Specification of conventional Yuguang battery
Battery model
5h rated capacity（Ah）
Rated voltage（V）
Reference appearance size（mm）
L
W
H
D330KT
330
2
136
179
460
D385KT
385
2
136
179
460
D440KT
440
2
173
179
460
D440KT(B)
440
2
125
158
515
D560KT
560
2
145
160
580
D560KT(A)
560
2
125
158
611
D450KT
450
2
93
158
625
DM330KT
330
2
182
140
390
DM385KT
385
2
182
140
390
DM440KT
440
2
180
166
390
-
1. The battery adopts acid-resistant exhaust plug and double pole, which is safe to use. The acid-resistant exhaust plug of the battery has undergone a water-repellent treatment to ensure that the battery has good air permeability, correct the working environment, and reduce the consumption of electrolyte water.
2. The armored positive plate made of the battery using advanced technology can prevent the positive active material from falling off and prolong its service life.
3. When the single cells are combined into a battery pack, use wire welding connection to prevent sparks, reduce contact resistance, and ensure safe use and unobstructed wiring.
4. In order to avoid short circuit of the battery pack, the conductive exposed parts are covered with an insulating sheath, and the wire connection surface is coated with sealant to prevent corrosion by sulfuric acid and ensure safe use.
5. The grid is made of excellent lead-calcium multi-element alloy, which has good conductivity, corrosion resistance and excellent circulation ability;
6. It is made of high-purity electrolytic lead and other materials, with low self-discharge and strong charge retention ability;
7. Valve-controlled sealing is realized, maintenance is more convenient than ordinary batteries, the number of times of adding pure water is less, acid mist pollution is reduced, and labor intensity is reduced.
-
This product mainly provides DC power supply for coal mine traction locomotives.
